Tube Clamp Scaffolding Coupler Fittings
Wellmade’s Scaffold Fittings is Scaffold Tube and Clamp System Components. It is Scaffolding Coupler Fixing and Connecting Between Scaffolding Pipes and Tubes. You can find All Types and All Sizes of Tube Clamp Scaffold Fittings Here.
- Right Angle Clamp
- Swivel Clamp
- Rigid Beam Clamp
- Swivel Beam Clamps
- Side By Side Clamps
- I Bolt&T Bolt Scaffolding Clamps
- 2″, 2.5″ and 3.5″ Scaffold Fittings
Wellmade’s I Bolt Right Angle Coupler is Manufactured to USA Scaffolding Companies. 2″ Dual Scaffolding Clamp Fixes Scaffold Tubes In 90 Degrees.
Wellmade’s I Bolt Swivel Clamp Fittings is the USA Type Scaffold Fittings. The Duo Scaffold Fittings Allows Scaffold Tube Connecting In Any Angles.
Rigid Beam Clamps are Used In Pairs. It Connect Scaffold Tubes with Scaffold Beams In Right Angle.
Side By Side Pipe Clamps is also Called Cheeseborough Clamp. It is a Special Drop Forged Scaffold Fittings For Scaffolding Frames.
Scaffold Fittings with T Bolt is different with I Bolt Clamps. Wellmade’s T Bolt Right Angle Couplers Supplying to Europe and the USA
Wellmade’s T Bolt Swivel Clamp Fitting in Drop Forged Connect Scaffold Tube In O.D 48.3mm(1.9″) Conform to EN 74 Standard
Scaffold Tube with End Fittings
Scaffold Tube with End Fittings is also called Tube Lock Scaffolding. Wellmade Produces All Sizes of Scaffold Tube with End Fittings. The Scaffold Tube is In Standard O.D 1.9″(48.3mm). Our Scaffold Tube with End Fittings is Hot Dip Galvanized Surface For Corrosion Resistant.
We Customized Your Scaffold Tube In Lengths. Our Scaffold Tube with End Fittings Makes Your Construction Scaffolding Easier Than Steel Tube without End Fittings.
- Size: 13′ In Length
- Diameter: 48.3mm(O.D 1.9″)
- Surface: Hot Dip Galvanized
- Feature: Easy Connecting In Construction
- Size: 16′ In Length
- Diameter: 48.3mm(O.D 1.9″)
- Surface: Hot Dip Galvanized
- Feature: Easy Connecting In Construction
- Size: 10′ In Length
- Diameter: 48.3mm(O.D 1.9″)
- Surface: Hot Dip Galvanized
- Feature: Easy Connecting In Construction
- Size: 8′ In Length
- Diameter: 48.3mm(O.D 1.9″)
- Surface: Hot Dip Galvanized
- Feature: Easy Connecting In Construction
- Size: 6′ In Length
- Diameter: 48.3mm(O.D 1.9″)
- Surface: Hot Dip Galvanized
- Feature: Easy Connecting In Construction
- Size: 20′ In Length
- Diameter: 48.3mm(O.D 1.9″)
- Surface: Hot Dip Galvanized
- Feature: Easy Connecting In Construction
- Scaffold Fittings Manufacturing Vedio
- Wellmade's Scaffold Beam Clamp In Test
More Types of Scaffold Fittings
Wellmade Customized Your Scaffold Fittings Size. You can Find Special Diameter Scaffold Fittings for Your Scaffolding Pipe & Pope. Include O.D 60.3mm(2.5″), O.D 76mm(3″), O.D 89mm (3 1/2″) & O.D 42.7mm(1.68″).
High-Quality Scaffold Fitting Manufacturer In China
Wellmade is The Leading Scaffold Fitting Manufacturer and Supplier In China. We Not Only Produce Scaffold Systems(Ringlock Scaffolding, Cuplock Scaffolding, Kwikstage Scaffolding, Frame Scaffolding, Quick Lock Scaffolding), but also Scaffold Fittings for All of System Scaffold. You can get One Stop Scaffolding Material Sourcing Here.
Wellmade’s Scaffold Fittings and Clamps are Tested according to EN, BS and ANSI (OSHA) Standard. You can Get Scaffold Fitting Test Result with Technical Data from Wellmade’s 3rd Party Test Report.
More than That, We Keep Daily Test According to the International Scaffolding Standard to Make Sure the Scaffold Fittings are Meet Up and More than Scaffolding Standard Requirement. We Ensure Scaffold Fittings Safety In Your Construction.
Wellmade is CE Certified Scaffolding Manufacturer In Europe. It is also Certified as Safety Scaffolding Material Brand In Australia and Award Product Certificated Licence (PCL) In Malaysia.
OEM Scaffold Fittings Manufacturer
With 20 years Scaffold Fittings OEM Manufacturing Experiences, Wellmade offers All Brands Scaffold Fittings. You can Get Free Customized Logo and Marks On Your Scaffold Products.
Door to Door Delivery Service
With More than 20 Years Scaffolding Supplying and Export Experience, Wellmade has It Strong Partnership In Global Wide. Thus, We are able to offer Door to Door Delivery for Your Scaffold Fittings.
Drop Forged Scaffold Fittings and Pressed Steel Scaffold Fittings
Drop Forged Scaffold Fittings
All of the Scaffold Fittings to the USA in I Bolt and T Bolt are Drop Forged Type Scaffold Fittings. It is the Most Popular Used Scaffold Fittings Suit for All Industries.
Pressed Steel Scaffold Fittings
There are also Pressed Steel Scaffold Fittings In Wellmade. You can find BS 1139 and En 74 Standard Pressed Double Clamps, Pressed Swivel Clamps, Pressed Putlog Couplers, Pressed Sleeve Coupler In Wellmade.
Authorized Oil and Gas Scaffolding Supplier
Wellmade is Authorized Oil and Gas Scaffolding Supplier In China. In the past 20 years, Wellmade Supplies Scaffold Fittings, Scaffold Tubes and Scaffold Boards System Scaffold to Shell, Sinopec, KNPC, China Petroleum etc.
Hot Dip Galvanized Scaffold Fittings VS Zinc-Plated Scaffold Fittings
In Wellmade, You can choose Hot dip galvanized Scaffold Fittings and Zinc-plated Scaffold Fittings.
Hot dip galvanized Scaffold Fittings Is Durable with Longer Life Span. It is Used In Onshore and Offshore Scaffolding Projects. Hot dip galvanized Scaffold Fittings Cost is More Higher Than Zinc-plated Scaffold Fittings.
Zinc Plated Scaffold Fittings is also Named E-galvanized or Cold Galvanized Scaffold Fittings. This is the Most Required Scaffold Fittings for Most Scaffolding Companies, Construction Companies and Contractors. Zinc-plated is not as good as Hot dip galvanized. But it is still Corrosion Resistance. Zinc Plated Scaffold Fittings is Cheaper than Hot Dip Couplers.
List of Scaffold Clamp Fittings for USA Market | ||||
| Code No. | Items | Weight | Surface Treatment | Nut Fitting Sp |
| RAC4848-I-USA | I Bolt Right Angle Coupler 48x48mm | 1.55 KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| RAC4848-T-USA | T Bolt Right Angle Coupler 48x48mm | 1.3KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW4848-I-USA | I Bolt Swivel Clamp 48x48mm | 1.7KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW4848-T-USA | T Bolt Swivel Clamp 48x48mm | 1.4KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW4860-USA | Swivel CLamp 48x60mm | 1.65KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW4242-USA | Swivel CLamp 42x42mm | 1.2KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW4860-USA | Swivel CLamp 48x60mm | 1.32KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW6060-USA | Swivel CLamp 60x60mm | 1.72KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW4876-USA | Swivel CLamp 48x76mm | 1.75KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW4889-USA | Swivel CLamp 48x89mm | 2.7KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SW8989-USA | Swivel CLamp 89x89mm | 3.5KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| HSW89-USA | Half Swivel Clamp 89mm | 1.68KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SDS42-USA | Side By Side Pipe Clamp | 0.75KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| FBC48 | Fixed Beam Clamp Fitting | 1.55 KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
| SBC48 | Swivel Beam Clamp Fitting | 1.85KG | HDG | Zinc-plated | 22mm Flange Nut, 8.8 Class |
Scaffold Tube with End Fittings Size&Spec | ||||
| No. | Size | Weight | Surface Treatment | |
| STL16 | 16 FT Scaffold Tube with Fittings | O.D 1.9″ x 16′ | 18.45KG | Hot Dip Galvanized (HDG) |
| STL13 | 13 FT Scaffold Tube with Fittings | O.D 1.9″ x 13′ | 15.21KG | Hot Dip Galvanized (HDG) |
| STL10 | 10 FT Scaffold Tube with Fittings | O.D 1.9″ x 10′ | 11.98KG | Hot Dip Galvanized (HDG) |
| STL08 | 8 FT Scaffold Tube with Fittings | O.D 1.9″ x 8′ | 9.83KG | Hot Dip Galvanized (HDG) |
| STL06 | 6 FT Scaffold Tube with Fittings | O.D 1.9″ x 6′ | 7.67KG | Hot Dip Galvanized (HDG) |
